Data Type Conversion Between MATLAB and Python: What’s New in R2024a

When combining MATLAB with Python® to create deep learning workflows, data type conversion between the two frameworks can be time consuming and sometimes perplexing. I 've certainly experimented with figuring out how to make MATLAB data compatible with a Python-based model and vice versa. So, you can understand why I am so excited that there are two new data type conversions introduced in MATLAB R2024a.
Data type conversion between MATLAB and Python

In the following table you can see the new data type conversions. And it came as no surprise to me that they made the list of Mike Croucher's favorite R2024a updates.
Python Data Type MATLAB Data Type
Pandas DataFrame MATLAB table
Python dictionary MATLAB dictionary
Python dictionary MATLAB structure
Performing the data type conversions is very easy and you can learn all the details in these documentation topics: Use Python Pandas DataFrames in MATLAB and Use Python Dictionaries in MATLAB. So, in this blog post, instead of showing you the code for all the possible conversions, I am going to walk you through an object detection example and present a use case for converting data from a Python dictionary to a MATLAB structure.


Object Detection Example

This example calls a PyTorch model from MATLAB to detect objects in the input image. When you call the PyTorch model you want to (1) pass MATLAB data to a format that the model can process and (2) convert the model outputs (Python data type) to a MATLAB data type that can be used in MATLAB for visualization, as shown here, but also as an input to the next steps in your workflow.

Python Environment

Set up the Python interpreter for MATLAB by using the pyenv function.
pe = pyenv(Version=".\env\Scripts\python.exe",ExecutionMode="OutOfProcess");

Python Code for Object Detection

The following Python code is saved in the PT_object_detection.py file, which you can call from MATLAB to perform object detection with a PyTorch model.
import torch
import torchvision as vision
import numpy

def loadPTmodel():
    # Initialize model with the best available weights
    weights = vision.models.detection.FasterRCNN_ResNet50_FPN_V2_Weights.DEFAULT
    model = vision.models.detection.fasterrcnn_resnet50_fpn_v2(weights=weights,box_score_thresh=0.95)
    model.eval()

    return model, weights

def detectPT(img,model,weights):
    # Reshape image and convert to a tensor.
    X = numpy.asarray(img)
    X_torch1 = torch.from_numpy(numpy.copy(X))
    if X_torch1.ndim==3:
      X_torch = torch.permute(X_torch1,(2,0,1))
    elif X_torch1.ndim==4:
      X_torch = torch.permute(X_torch1,(3,2,0,1))
    # Initialize the inference transforms
    preprocess = weights.transforms()
    # Apply inference preprocessing transforms
    batch = [preprocess(X_torch)]
    # Use the model
    if X_torch.ndim==3:
      prediction = model(batch)[0]
    elif X_torch.ndim==4:
      prediction = model(list(batch[0]))

    return prediction

Object Detection

Read the image that you want to use for object detection.
img_filename = "testCar.png";
img = imread(img_filename);
Perform object detection with a PyTorch model using co-execution.
pyrun("from PT_object_detection import loadPTmodel, detectPT")
[model,weights] = pyrun("[a,b] = loadPTmodel()",["a" "b"]);
predictions_pt = pyrun("a = detectPT(b,c,d)","a",b=img,c=model,d=weights);
The output of the object detector is a Python dictionary.
class(predictions_pt)
ans = 'py.dict'

Convert Predictions

Convert the objection detection results from a Python dictionary to a MATLAB structure.
predictions = struct(predictions_pt)
predictions = struct with fields:
     boxes: [1×1 py.torch.Tensor]
    labels: [1×1 py.torch.Tensor]
    scores: [1×1 py.torch.Tensor]
The data variables in the structure prediction are PyTorch tensors. Convert the variables into MATLAB arrays.
predictions.boxes = double(predictions.boxes.detach().numpy);
predictions.labels = double(predictions.labels.tolist)';
predictions.scores = double(predictions.scores.tolist)';
predictions
predictions = struct with fields:
     boxes: [4×4 double]
    labels: [4×1 double]
    scores: [4×1 double]
The bounding boxes require further processing to align with the input image.  A bounding box is an axis-aligned rectangle defined in spatial coordinates as an Mx4 numeric matrix with rows of the form [x y w h], where:
  • M is the number of axis-aligned rectangles.
  • x and y specify the upper-left corner of the rectangle.
  • w specifies the width of the rectangle, which is its length along the x-axis.
  • h specifies the height of the rectangle, which is its length along the y-axis.
predictions.boxes = cat(2,predictions.boxes(:,1:2)+1,predictions.boxes(:,3:4)/2);
Get the class labels. The PyTorch model was trained on the COCO data set.
class_labels = getClassLabels(predictions.labels);

Visualization

Create the labels associated with each of the detected objects.
num_box = length(predictions.scores);
colons = repmat(": ",[1 num_box]);
percents = repmat("%",[1 num_box]);
class_labels1 = strcat(class_labels,colons,string(round(predictions.scores'*100)),percents);
Visualize the object detection results with annotations.
figure
outputImage = insertObjectAnnotation(img,...
    "rectangle",predictions.boxes,class_labels1,LineWidth=1,Color="green");
imshow(outputImage)
So, you can see the object detection was successful with a high degree of confidence.
|
