A Matrix for the New HPL-AI Benchmark

My colleagues are looking for a matrix to be used in a new benchmark. They've come to the right place.

Contents

Email

A couple of weeks ago I got this email from Jack Dongarra at the University of Tennessee.

For this new HPL-AI benchmark, I'm looking for a matrix that is not symmetric, is easily generated (roughly O(n^2) ops to generate), is dense, doesn’t require pivoting to control growth, and has a smallish condition number (<O(10^5)).

There are two steps for the benchmark:

1) do LU on the matrix in short precision and compute an approximation solution x. (On Nvidia this is 6 times faster in half precision then in DP.)

2) do GMRES on with L and U as preconditions with x as the starting point (this usually takes 3-4 iterations to converge.)

The benchmark details are here: http://bit.ly/hpl-ai.

Any ideas for a matrix?

Symmetric Hilbert Matrix

One of the first matrices I ever studied was the Hilbert matrix. With the singleton expansion features now in MATLAB, the traditional symmetric Hilbert matrix can be generated by

  format rat
  n = 5;
  i = 1:n
  j = i'
  H = 1./(i+j-1)
i =
       1              2              3              4              5
j =
       1
       2
       3
       4
       5
H =
       1              1/2            1/3            1/4            1/5
       1/2            1/3            1/4            1/5            1/6
       1/3            1/4            1/5            1/6            1/7
       1/4            1/5            1/6            1/7            1/8
       1/5            1/6            1/7            1/8            1/9

When you add the row vector i to the column vector j, the resulting i+j is a matrix. Compare this with the inner product, i*j, which produces a scalar, and the outer product, j*i, which produces another matrix. The expression i+j can be thought of as an "outer sum".

Two more scalar expansions complete the computation; i+j-1 subtracts 1 from each element of the sum and 1./(i+j-1) divides 1 by each element in the denominator. Both of these scalar expansions have been in MATLAB from its earliest days.

The elements of Hilbert matrices depend only on the sum i+j, so they are constant on the antidiagonals. Such matrices are known as Cauchy matrices. There are fast algorithms for solving system of equations involving Cauchy matrices in $O(n^2)$ time.

Nonsymmetric Hilbert Matrix

Some years ago, I wanted a nonsymmetric test matrix, so I changed the plus sign in the denominator of the Hilbert matrix to a minus sign. But this created a division by zero along the subdiagonal, so I also changed the -1 to +1/2. I call this the "nonsymmetric Hilbert matrix."

   H = 1./(i-j+1/2)
H =
       2              2/3            2/5            2/7            2/9
      -2              2              2/3            2/5            2/7
      -2/3           -2              2              2/3            2/5
      -2/5           -2/3           -2              2              2/3
      -2/7           -2/5           -2/3           -2              2

The elements depend only on i-j and so are constant on the diagonals. The matrices are Toeplitz and, again, such systems can be solved with $O(n^2)$ operations.

I was astonished when I first computed the singular values of nonsymmetric Hilbert matrices -- most of them were nearly equal to $\pi$. Already with only the 5-by-5 we see five decimal places.

   format long
   sigma = svd(H)
sigma =
   3.141589238341321
   3.141272220456508
   3.129520593545258
   2.921860834913688
   1.461864493324889

This was a big surprise. The eventual explanation, provided by Seymour Parter, involves a theorem of Szego from the 1920's relating the eigenvalues of Toeplitz matrices to Fourier series and square waves.

Benchmark Matrix

I have been working with Jack's colleague Piotr Luszczek. This is our suggestion for the HPL-AI Benchmark Matrix. It depends upon two parameters, n and mu. As mu goes from 1 to -1, the core of this matrix goes from the symmetric to the nonsymmetric Hilbert matrix. Adding n in the denominator and 1's on the diagonal produces diagonal dominance.

   A = 1./(i + mu*j + n) + double(i==j);
   clear A
   type A
function Aout = A(n,mu)
% A(n,mu).  Matrix for the HPL-AI Benchmark.  mu usually in [-1, 1].
    i = 1:n;
    j = i';
    Aout = 1./(i+mu*j+n) + eye(n,n);
end

If mu is not equal to +1, this matrix is not Cauchy. And, if mu is not equal to -1, it is not Toeplitz. Furthermore, if mu is greater than -1, it is diagonally dominant and, as we shall see, very well-conditioned.

Example

Here is the 5x5 with rational output. When mu is +1, we get a section of a symmetric Hilbert matrix plus 1's on the diagonal.

   format rat
   mu = 1;
   A(n,mu)
ans =
       8/7            1/8            1/9            1/10           1/11
       1/8           10/9            1/10           1/11           1/12
       1/9            1/10          12/11           1/12           1/13
       1/10           1/11           1/12          14/13           1/14
       1/11           1/12           1/13           1/14          16/15

And when mu is -1, the matrix is far from symmetric. The element in the far southwest corner almost dominates the diagonal.

   mu = -1;
   A(n,mu)
ans =
       6/5            1/6            1/7            1/8            1/9
       1/4            6/5            1/6            1/7            1/8
       1/3            1/4            6/5            1/6            1/7
       1/2            1/3            1/4            6/5            1/6
       1              1/2            1/3            1/4            6/5

Animation

Here is an animation of the matrix without the addition of eye(n,n). As mu goes to -1 to 1, A(n,mu)-eye(n,n) goes from nonsymmetric to symmetric.

Gaussian elimination

If mu > -1, the largest element is on the diagonal and lu(A(n,mu)) does no pivoting.

   format short
   mu = -1
   [L,U] = lu(A(n,mu))

   mu = 1
   [L,U] = lu(A(n,mu))
mu =
    -1
L =
    1.0000         0         0         0         0
    0.2083    1.0000         0         0         0
    0.2778    0.1748    1.0000         0         0
    0.4167    0.2265    0.1403    1.0000         0
    0.8333    0.3099    0.1512    0.0839    1.0000
U =
    1.2000    0.1667    0.1429    0.1250    0.1111
         0    1.1653    0.1369    0.1168    0.1019
         0         0    1.1364    0.1115    0.0942
         0         0         0    1.1058    0.0841
         0         0         0         0    1.0545
mu =
     1
L =
    1.0000         0         0         0         0
    0.1094    1.0000         0         0         0
    0.0972    0.0800    1.0000         0         0
    0.0875    0.0729    0.0626    1.0000         0
    0.0795    0.0669    0.0580    0.0513    1.0000
U =
    1.1429    0.1250    0.1111    0.1000    0.0909
         0    1.0974    0.0878    0.0800    0.0734
         0         0    1.0731    0.0672    0.0622
         0         0         0    1.0581    0.0542
         0         0         0         0    1.0481

Condition

Let's see how the 2-condition number, $\sigma_1/\sigma_n$, varies as the parameters vary. Computing the singular values for all the matrices in the following plots takes a little over 10 minutes on my laptop.

sigma_1

   load HPLAI.mat s1 sn n mu

   surf(mu,n,s1)
   view(25,12)
   xlabel('mu')
   ylabel('n')
   set(gca,'xlim',[-0.9 1.0], ...
       'xtick',[-0.9 -0.5 0 0.5 1.0], ...
       'ylim',[0 2500])
   title('\sigma_1')

The colors vary as mu varies from -0.9 up to 1.0. I am staying away from mu = -1.0 where the matrix looses diagonal dominance. The other horizontal axis is the matrix order n. I have limited n to 2500 in these experiments.

The point to be made is that if mu > -0.9, then the largest singular value is bounded, in fact sigma_1 < 2.3.

sigma_n

   surf(mu,n,sn)
   view(25,12)
   xlabel('mu')
   ylabel('n')
   set(gca,'xlim',[-0.9 1.0], ...
       'xtick',[-0.9 -0.5 0 0.5 1.0], ...
       'ylim',[0 2500])
   title('\sigma_n')

If mu > -0.9, then the smallest singular value is bounded away from zero, in fact sigma_n > .75.

sigma_1/sigma_n

   surf(mu,n,s1./sn)
   view(25,12)
   xlabel('mu')
   ylabel('n')
   set(gca,'xlim',[-0.9 1.0], ...
       'xtick',[-0.9 -0.5 0 0.5 1.0], ...
       'ylim',[0 2500])
   title('\sigma_1/\sigma_n')

If mu > -0.9, then the condition number in the 2-norm is bounded, sigma_1/sigma_n < 2.3/.75 $\approx$ 3.0 .

Overflow

The HPL-AI benchmark would begin by computing the LU decomposition of this matrix using 16-bit half-precision floating point arithmetic, FP16. So, there is a signigant problem if the matrix order n is larger than 65504. This value is realmax, the largest number that can be represented in FP16. Any larger value of n overflows to Inf.

Some kind of scaling is going to have to be done for n > 65504. Right now, I don't see what this might be.

The alternative half-precision format to FP16 is Bfloat16, which has three more bits in the exponent to give realmax = 3.39e38. There should be no overflow problems while generating this matrix with Bfloat16.

Thanks

Thanks to Piotr Luszczek for working with me on this. We have more work to do.
